Precision CNC Machined Dual-Port Manifold Connector

Xiangxing Xin is a Precision CNC Machined Dual-Port Manifold Connector manufacturer for compact components where two passages, multiple diameters and several assembly references must be integrated into one machined body. The twin front ports can connect with mating tubes, sleeves or other customer-designed components, while the larger stepped body provides structural support and positioning surfaces.

The two ports are not simply repeated cylindrical features. Their center distance, relative height, bore size and relationship to the main body can directly affect downstream assembly. For this reason, machining and inspection should treat the dual-port section as one functional feature group rather than checking each opening independently.

Behind the port area, the component transitions through several diameters before reaching the rear flange. These shoulders can provide installation references, insertion limits or mating positions within a larger mechanical system. The rear flange may also be used as an axial stop or mounting reference depending on the customer design.

Material and process selection should follow the actual working environment. Aluminum alloys are suitable where lower weight and good machinability are important, while stainless steel, alloy steel, brass or copper-based materials may be selected for different strength, corrosion, conductivity or application requirements. Surface treatment and additional finishing can be arranged according to the confirmed specification.

For production control, Xiamen Xiangxing Xin Industry and Trade Co., Ltd. can focus inspection on the dual-port center distance, individual bore dimensions, stepped outside diameters, shoulder locations, flange position and other drawing-defined mating features, helping the completed part enter the customer’s assembly with fewer dimensional adjustments.

Specifications

Product Advantages

Integrated Dual-Port Construction

Two connection passages are incorporated into one machined body, reducing the number of separate components required in assemblies designed around an integrated connector.

Controlled Port Center Distance

The positional relationship between both ports can be machined and inspected as a functional group, which is especially important when they connect directly with another dual-port component.

Multiple Positioning References

The stepped body provides several possible locating surfaces. Different diameters and shoulders can be assigned to insertion, support, sealing or axial-positioning functions according to the customer drawing.

Flexible Material Selection

The same structural concept can be produced in different machinable metals according to strength, weight, corrosion resistance, conductivity and service-environment requirements.

Drawing-Based Functional Inspection

For a Precision CNC Machined Dual-Port Manifold Connector, inspection can concentrate on dimensions that influence actual assembly rather than applying unnecessarily tight tolerances to every surface.

Product Comparison

FAQ

Q1: Can the two ports have different diameters?

Yes. The two passages do not need to be identical. Port diameter, depth, wall thickness and center distance can all follow the customer drawing.

Q2: Can you control the center distance between the two ports?

Yes. The center distance can be treated as a critical functional dimension when it directly affects mating-part installation.

Q3: What materials can be used?

Material can be selected according to the application, including aluminum alloys, stainless steels, carbon or alloy steels, brass, copper and other confirmed machinable materials.

Q4: What is your MOQ?

Xiangxing Xin can support prototype production starting from 1 piece for drawing-based custom components.

Q5: What payment methods do you accept?

Payment terms and available payment methods are confirmed in the quotation or Proforma Invoice according to the order value and cooperation stage. Please contact us for the applicable option for your order.

Q6: What files should I send for quotation?

2D drawings in PDF or DWG/DXF format and 3D files such as STEP, IGES or SolidWorks are useful. Please also indicate material, quantity, critical tolerances and surface-treatment requirements.

Direct Factory Advantages

For OEM connector and manifold projects, Xiamen Xiangxing Xin Industry and Trade Co., Ltd. provides Xiangxing Xin direct manufacturing support for the Precision CNC Machined Dual-Port Manifold Connector, covering drawing review, turning, milling, inspection and repeat production.

CNC Turning + Turn-Mill Capability

The factory is equipped with CNC lathes and turn-mill machines, making it possible to combine concentric cylindrical surfaces with offset holes, twin ports and additional machined details in a coordinated process.

Multi-Axis Machining Support

3-axis, 4-axis and 5-axis machining capacity provides additional flexibility when a connector body contains side holes, angled features, irregular port positions or secondary milling requirements.

Prototype From 1 Piece

MOQ can start from 1 piece, making it easier for customers to verify port fit, center distance and assembly relationships before committing to production quantities.

Critical Tolerance Capability

General machining can typically reach ±0.01 mm, while selected critical areas can be evaluated for tighter ±0.005–0.002 mm requirements according to material, geometry and inspection conditions.

Inspection Based on Assembly Function

Instead of focusing only on appearance, inspection can prioritize functional dimensions such as port diameter, center spacing, concentricity, shoulder location and mating surfaces.

Fast Sample Development

For suitable projects with confirmed drawings and materials, sample production can typically be arranged within 3–5 days, helping OEM customers shorten the design-verification cycle.
