Xiamen Xiangxing Xin Industry and Trade Co., Ltd. manufactures the Custom CNC Machined Flange Mounting Plate according to customer drawings, 3D models or physical samples. The product features a circular body, central bore, evenly distributed mounting holes, recessed inner surface and curved slots. These structures can be customized to match different equipment interfaces, positioning requirements and mechanical assemblies.
As a professional manufacturer, we combine CNC turning, milling and drilling to complete the required rotational and non-rotational features. CNC turning can be used for the outside diameter, center bore, end faces, stepped surfaces and circular recesses. CNC milling and drilling can then produce mounting holes, slots and other positioning features. After machining, the parts can be deburred, cleaned and finished according to the approved technical requirements.
The material of the product can be selected according to strength, weight, corrosion resistance, operating environment and project budget. Available solutions may include aluminum alloy, stainless steel, carbon steel, brass or other machinable metals, subject to drawing confirmation. The product can be used as a mounting interface, retaining plate, connecting component or structural support in industrial machinery, automation equipment, fixtures and custom mechanical devices.
Xiamen Xiangxingxin Industry and Trade Co., Ltd. produces the Custom CNC Machined Flange Mounting Plate with drawing-based customization and flexible material selection.
The outside diameter, center bore, plate thickness, hole quantity, hole spacing, recessed surface and curved-slot position can be produced according to the approved drawing.
The mounting holes, positioning surfaces, circular recesses and slots can be integrated into one component, helping simplify the mechanical assembly and reduce the need for additional connecting parts.
Aluminum alloy, stainless steel, carbon steel, brass and other machinable metals can be evaluated according to strength, weight, corrosion resistance, appearance and cost requirements.
The project can be evaluated from a 2D drawing, 3D model or physical sample. After the specifications are confirmed, the same technical documents can be used for sample verification and repeat batch production.
| Parameter | Details |
| Product Name | Custom CNC Machined Flange Mounting Plate |
| Manufacturer | Xiamen Xiangxingxin Industry and Trade Co., Ltd. |
| Supplier Type | Custom CNC Machined Flange Mounting Plate Manufacturer |
| Product Type | Custom Circular Flange / Mounting Plate |
| Shape | Circular |
| Main Features | Center Bore, Mounting Holes, Recessed Pocket and Curved Slots |
| Material | Aluminum Alloy, Stainless Steel, Carbon Steel, Brass or According to Drawing |
| Manufacturing Method | CNC Turning, CNC Milling and Drilling |
| Outside Diameter | According to Customer Drawing |
| Center Bore | According to Customer Drawing |
| Thickness | According to Customer Drawing |
| Hole Pattern | Customized According to Drawing |
| Slot Position | Customized According to Drawing |
| Tolerance | According to Drawing and Functional Requirements |
| Surface Finish | Machined Finish or Customized Surface Treatment |
| Application | Industrial Machinery, Automation Equipment, Fixtures and Mechanical Assemblies |
| Customization | OEM, Drawing-Based or Sample-Based Production |
| MOQ | To Be Confirmed |
| Lead Time | To Be Confirmed After Drawing Review |
| Inspection | Dimensional and Visual Inspection According to Approved Drawing |
| Packaging | According to Product Size and Customer Requirements |
| Process | Description |
| Drawing Review | Confirm dimensions, tolerances, hole positions, slot geometry, material and surface requirements. |
| Material Confirmation | Select the required material grade and raw-material dimensions. |
| Blank Preparation | Prepare round bar, plate or a suitable near-net-shape blank. |
| CNC Turning | Machine the outside diameter, center bore, end faces, stepped surfaces and circular recesses. |
| CNC Milling | Produce curved slots, locating features and other non-rotational structures. |
| Drilling | Machine the mounting holes according to the specified quantity, diameter and position. |
| Deburring | Remove sharp edges and machining burrs from holes, slots and external edges. |
| Surface Treatment | Apply the required finish according to the material and operating environment. |
| Quality Inspection | Inspect critical dimensions, hole positions, appearance and drawing requirements. |
| Cleaning and Packaging | Clean and protect the parts before packaging and shipment. |
Yes. As a Custom CNC Machined Flange Mounting Plate Manufacturer, we can evaluate the outside diameter, center bore, thickness, mounting holes, recessed surfaces and curved slots according to your 2D drawing or 3D model.
Common options may include aluminum alloy, stainless steel, carbon steel and brass. The final material grade should be selected according to the required strength, weight, corrosion resistance and operating environment.
Please provide the 2D drawing or 3D model, material grade, order quantity, dimensional tolerances, surface treatment, application and critical inspection requirements.
Prototype production can be evaluated after the drawing, material and machining requirements are reviewed. The sample arrangement and production time will be confirmed according to the project.
Yes. The hole quantity, diameter, spacing, position and slot geometry can be machined according to the approved technical drawing.
The available surface treatment depends on the selected material and operating environment. Options can be evaluated after the customer provides the required appearance, corrosion-resistance and functional requirements.
